BREATHE SAFE - INTELLIGENT CABIN AIR FILTRATION

ISS Mine Safety is proud to distribute Breathe Safe products to Canadian and other North American mining regions. Breathe Safe is an Australian owned company dedicated to developing the very best products for filtering hazardous materials.

breathe safe logo.png


Breathe Safe offers the Complete Solution to your Air Quality Requirements

  • HEPA and Activated Carbon Cabin Pressurization Systems

  • HEPA Return Air Filtration

  • Cabin Pressure Monitoring

  • Auto Pressure Control (will maintain a pre-set value)

  • Cabin Sealing

  • Proven to Reduce Maintenance Costs through Efficient Design

Custom Designed Systems to suit the Harshest Environments

  • Maintenance Free Brushless Motors

  • Auto Cabin Pressurization

  • H13 / H14 grade HEPA Filters

  • Install kits designed for the life of the machine

  • Best Warranty in the Industry

Dust Particle Content: Coal Dust
Health Effect: Pneumoconiosis (e.g. coal workers’ pneumoconiosis or ‘black lung’) and chronic obstructive pulmonary disease (COPD) such as bronchitis and emphysema.

Invisible Risk
Airborne particulate pollution is classified as particulate matter (PM):

  • PM10 Particles that are less than 10 microns in diameter

  • PM2.5 Particles that are less than 2.5 microns in diameter

Industrial worksites may have high exposure levels to harmful substances within PM10 and PM2.5 such as fibres, silica dust, coal dust, metals, plastics, VOCs, toxic particles from Diesel Particulate Matter and more.

Particulate smaller than 10 microns (PM10) in size will reach deep into lung tissue as the human body lacks defense mechanisms. (Difficult to expel by exhaling, coughing or by mucus).

Particulate Matter - Invisible Risk

Particulate Matter - Invisible Risk

Cabin Air Filtration with HEPA Filter
Cabin Pressurizer is mounted outside the cabin. It will clean the air with a HEPA H13 filter and then force it into the cabin through the air conditioning to pressurize the cabin with HEPA filtered air.

Return air filter (RAF) isolates the HVAC system thus air out of the vents delivers a SAFE BREATHING ZONE.

Cabin Air Filtration with HEPA Filter

Cabin Air Filtration with HEPA Filter

Why HEPA?
HEPA filters capture respirable dust down to 0.3 microns (MPPS) at 99.97% efficiency (HEPA H13).

Effective for silica dust, coal dust, DPM, mould, VOCs, fibrous materials (asbestos), nuisance dust, pollen, wood dust, grain dust and airborne particles specifically in the respirable range 0.3 to 10 micron diameter.

Occupational benchmark going forward:

  • The breathing zone of the operator must be dust free!

  • This is specifically the occupational requirement for silica (respirable) dust.

Breathe Safe EN15695 Category 4 System in Qualifying Cabin:
(Effective cabin sealing and (HEPA) High Efficiency Particulate Air)

Stage 1:
Pre-cleaner - Removes up to 90% of coarse particles from fresh air.

Stage 2:
Pressurizer with High Efficiency Particulate Air (HEPA) filter - Removes fine dust particles and protects the activated carbon media from premature dust loading.

Stage 3:
Impregnated activated carbon (Chemical) filter - Removes gaseous contaminates from air stream. Media is manufactured in blocks (solid core) to cope with vibration.

Stage 4:
Particulate HEPA final filter - Remove any other finer particles that remain from chemical filter.

Stage 5:
HEPA return air filter (Internal filter) - Remove any airborne contaminants from shoes or clothes.


Air Filtration - Category 4 System

Air Filtration - Category 4 System



Contact our ISS Solutions Team to learn more about how Breathe Safe Intelligent Cabin Air Filtration can protect your operators.
